Z35033 IPS Panel 3.5 Inch 480*800 TFT LCD Module SPI+RGB/MIPI Interface ST7701S Controller

  • Size:3.5" diagonal

  • Resolution:  480×800 pixels (WVGA)

  • Interface:SPI+RGB/MIPI

  • Driver IC:ST7701S–reliable and widely supported

  • Display Type: IPS panel with 80/80/80/80 viewing

  • Custom Services: Touch panel bonding, FPC design, brightness adjustment, cover lens, logo silk print

  • ISO9001,IATF16949,ROHS,REACH certified factory


Request A Quote
Z35033
Z35033
Z35033
Z35033

Overview of Z35033 3.5 Inch 480x800 TFT LCD Module SPI+RGB Interface ST7701S Driver IC

1

Z35033 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) .This 3.5 inch TFT LCD module features a 480x800 high-resolution display with an ST7701S controller. Designed with dual interface options—SPI+RGB or MIPI—it offers excellent flexibility for a variety of embedded applications. The IPS panel delivers vibrant colors and wide viewing angles.

2

If you have special requirement,like driver IC,interface,FPC,touch panel,backlight etc, we can also customize for you.

3

 Our factory carry out ISO 9001:2015 and IATF16949: 2016 quality standard system strictly, all the lcd display passed ROHS, REACH Certification

4

The 3.5" IPS LCD Screen is perfect for Home Intercom Systems,Smart Door Locks,Smart Thermostats,coffee makers, cookers/lighting/blinds control panel,IoT Controllers, remote control terminals,Wearable Tech Docking Stations,barcode scanners, data collectors,Access Control Devices,multimeters, analyzers,Digital Gauges,POS Machines,Ticketing Terminals,Price Checkers

Specifications of Z35033 3.5 Inch 480x800 TFT LCD Module SPI+RGB Interface ST7701S Driver IC


No.ItemSpecificationUnit
1Display Size (Diagonal)3.5inch
2Display Resolution480(H） × RGB × 800（V）pixels
3Pixel Pitch94.5(H） × 94.5（V）um
4T-LCM Outline Dimension (Without FPC）51.32(W) ×86.64 (H) ×3.7(T)mm
5LCM Outline Dimension (Without FPC）51.32(W) ×86.61 (H) ×2. 12(T)mm
6LCD Active Area45.36（W） ×75.60（H）mm
7View Direction (Gray Inversion)FULL VIEW-
8Driver ICST7701S-G5-
9Pixel ArrangementRGB-Stripe-
10Display ModeNormal Black-
11Pixel driving Elementa-Si TFT-
12LCD TransmittanceTyp.: 4.5%    Min:4.05%-
13LCD Contrast RatioTyp.: 1000    Min:800-
14FPC VersionZ35033-P40 V1-
15InterfaceSPI+RGB 16bit-
16Operating Temperature-20°C~ 70°C-
17Storage Temperature-30°C~ 80°C-
18Backlight ArrangementLED/7 Series 1 Parallel (7lights in total)-
19Luminance250nit
20Weight0.017kg


Interface Definition Description of Z35033 3.5 Inch 480x800 TFT LCD Module SPI+RGB Interface ST7701S Driver IC


PIN NO.

PIN DEF.

FUNCTION DESC.

1

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

2

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

3

GNG

Ground

4

VCC

POWER SUPPLY（2.8V/3.3V）

5-13

GND

Ground

14

VS（VSYNC）

Vertical sync. Signal in RGB I/F.

15

HS(HSYNC)

Horizontal sync. Signal in RGB I/F.

16

DCLK

Dot clock signal for RGB interface operation.

17

DE

Data enable signal for RGB interface operation.

18-22

DB0~DB4

BLUE    DATA(B0~B4)

23-28

DB5~DB10

GREEN    DATA (G0~G5)

29-33

DB11~DB15

RED    DATA (R0~R4)

34

RST

LCM    RESET    PIN

35

CS

Chip Select input PIN

36

SCL

LCM    SPI    clock (SCL) clock (SCLK)

37

SDA

LCM    SPI    data (SDA) data input (MOSI)

38

IOVCC

I/O    POWER SUPPLY

39

GND

Ground

40

IOVCC

I/O    POWER SUPPLY

RST voltage should be consistent with IOVCC voltage, or there probably is black screen fault when power on.
