Z103002 10.25 inch 1920*720 IPS LCD Display Strectched Bar Type LVDS Interface 600 cd/m2

  • Size:10.25"

  • Resolution: 1920*720

  • LCD Interface: LVDS

  • View Angle: IPS

  • Supply Type: Factory/Manufacturer

  • Certification:ISO9001,IATF16949,ROHS,REACH

z103002 1
z103002 1
z103002 2
z103002 3
z103002 4
z103002 5

Overview of Z103002 10.25 inch 1920*720 IPS LCD Display Strectched Bar Type LVDS Interface 600 cd/m2

1

 Z103002 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1920*720resolution. IPS(In-plane Switching) technique make this 10.25" LCD module have a wider view angle.This a-Si TFT LCD come with mipi interface.

2

If you have special requirement,like driver IC,interface,FPC,touch panel,backlight etc, we can customize for you.

3

Our factory carry out ISO 9001:2015 and IATF16949: 2016 quality standard system strictly, all the lcd display passed ROHS, REACH Certification

4

The 10.25" ultra wide LCD panel is widely used on Digital signage, information display, menu board, dashboard, conference room, gaming, advertising, kiosk, audio, VR, AR,POS, medical, HMI, navigation, education  etc

General Specifications 10.25 inch 1920*720 IPS LCD Display Strectched Bar Type LVDS Interface 600 cd/m2

NO.

Item

Specification

1

Display  resolution  (pixel)

1920*RGB*720

2

Active area (mm)

243.648mm x 91.368mm

3

Screen  size (inch)

10.25

4

Pixel pitc    (mm)

0.1269mm x 0.1269mm

5

Outline Dimension  (mm)

265.2mm x 109.2mm x 9.35mm

6

Weight (g)

110g

7

Surface treatment

HC/HC

8

Interface

LVDS

9

Shipment

FOG

10

Contrast ratio

1100

11

Response Time

20ms

12

Transmittance

2.4%


Interface Definition Description 10.25 inch 1920*720 IPS LCD Display Strectched Bar Type LVDS Interface 600 cd/m2

Pin NO.

Symbol

I/O

Description

Note


1

GND

P

Ground



2

GND

P

Ground



3

GND

P

Ground



4

VDD

P

External main and I/O power supply ; +3.3V



5

VDD

P

External main and I/O power supply ; +3.3V



6

VDD

P

External main and I/O power supply ; +3.3V



7

VDD

P

External main and I/O power supply ; +3.3V



8

GND

P

Ground



9

NC

-

Not connect



10

NC

-

Not connect



11

NC

-

Not connect



12

GND

P

Ground



13

OLV0P

I

LVDS odd data 0-



14

OLV0P

I

LVDS odd data 0+



15

GND

P

Ground



16

OLV1N

I

LVDS odd data 1-



17

OLV1P

I

LVDS odd data 1+



18

GND

P

Ground



19

OLV2N

I

LVDS odd data 2-



20

OLV2P

I

LVDS odd data 2+



21

GND

P

Ground



22

OLVCLKN

I

LVDS odd clk -



23

OLVCLKP

I

LVDS odd clk +



24

GND

P

Ground



25

OLV3N

I

LVDS odd data 3-



26

OLV3N

I

LVDS odd data 3-



27

GND

P

Ground



28

ELV0N

I

LVDS even data 0-



29

ELV0P

I

LVDS even data 0+



30

GND

P

Ground



31

ELV1N

I

LVDS even data 1-



32

ELV1P

I

LVDS even data 1+



33

GND

P

Ground



34

ELV2N

I

LVDS even data 2-



35

ELV2P

I

LVDS even data 2+



36

GND

P

Ground



37

ELVCLKN

I

LVDS even clk -



38

ELVCLKP

I

LVDS even clk +



39

GND

P

Ground



40

ELV3N

I

LVDS even data 3-



41

ELV3P

I

LVDS even data 3+



42

GND

P

Ground




43


RESET


I

Global reset pin

RESET="H",normal operation.(Default)

RESET="L",LCM is in reset state.




44


STBYB


I

Standby mode control.

STBYB="H",normal operation.

STBYB="L",LCM is in standby state.(Default)




45


SHLR


I

Horizontal shift direction (source output) selection. RL = "H": Left -> Right(default)

RL = "L": Right -> Left




46


UPDN


I

Vertical shift direction (gate output) selection. TB = "H": Top ->Bottom (default)

TB = "L": Bottom->Top



47

NC

-

Not connect



48

GND

P

Ground




49


BIST


I

Enable bult-in selftest (BIST)function

BIST=H,BIST Mode

BIST=L,Normal Mode



50

NC

-

Not connect
