Z103002 Stretched Bar Type 10.25 Inch Ultra Wide LCD Panel 1920*720 Support HDMI Android

  • Size:10.25"

  • Resolution:1920*720

  • Interface:LVDS

  • Supply Type: Factory/Manufacturer

  • Certification:ISO9001,IATF16949,ROHS,REACH

ips display
ips display
ips display module
ips display panel
ips lcd display
ips lcd display module

Overview of Z103002 Stretched Bar Type 10.25 Inch Ultra Wide LCD Panel 1920*720 Support HDMI Android

1

Z103002 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1920*720 resolution. IPS(In-plane Switching) technique make this 10.25" LCD module have a wider view angle.This a-Si TFT LCD come with LVDS interface.

2

If you have special requirement,like driver IC,interface,FPC,touch panel,backlight etc, we can also customize for you.

3

Our factory carry out ISO 9001:2015 and IATF16949: 2016 quality standard system strictly, all the lcd display passed ROHS, REACH Certification.

4

The 10.25" bar lcd screen is wide used on Digital signage, information display, menu board, dashboard, conference room, gaming, advertising, kiosk, audio, VR, AR,POS, medical, HMI, navigation, education etc.

General Specifications Z103002 Stretched Bar Type 10.25 Inch Ultra Wide LCD Panel 1920*720 Support HDMI Android


NO.

Item

Specification

1

Display  resolution  (pixel)

1920*RGB*720

2

Active area (mm)

243.648mm x 91.368mm

3

Screen  size (inch)

10.25

4

Pixel pitc    (mm)

0.1269mm x 0.1269mm

5

Outline Dimension  (mm)

265.2mm x 109.2mm x 9.35mm

6

Weight (g)

110g

7

Surface treatment

HC/HC

8

Interface

LVDS

9

Shipment

FOG

10

Contrast ratio

1100

11

Response Time

20ms

12

Transmittance

2.4%



Interface Pin Connection Z103002 Stretched Bar Type 10.25 Inch Ultra Wide LCD Panel 1920*720 Support HDMI Android


Pin NO.

Symbol

I/O

Description

Note

1

GND

P

Ground


2

GND

P

Ground


3

GND

P

Ground


4

VDD

P

External main and I/O power supply ; +3.3V


5

VDD

P

External main and I/O power supply ; +3.3V


6

VDD

P

External main and I/O power supply ; +3.3V


7

VDD

P

External main and I/O power supply ; +3.3V


8

GND

P

Ground


9

NC

-

Not connect


10

NC

-

Not connect


11

NC

-

Not connect


12

GND

P

Ground


13

OLV0P

I

LVDS odd data 0-


14

OLV0P

I

LVDS odd data 0+


15

GND

P

Ground


16

OLV1N

I

LVDS odd data 1-


17

OLV1P

I

LVDS odd data 1+


18

GND

P

Ground


19

OLV2N

I

LVDS odd data 2-


20

OLV2P

I

LVDS odd data 2+


21

GND

P

Ground


22

OLVCLKN

I

LVDS odd clk -


23

OLVCLKP

I

LVDS odd clk +


24

GND

P

Ground


25

OLV3N

I

LVDS odd data 3-


26

OLV3N

I

LVDS odd data 3-


27

GND

P

Ground


28

ELV0N

I

LVDS even data 0-


29

ELV0P

I

LVDS even data 0+


30

GND

P

Ground
