Z20001 240*320 2 Inch LCD Display Module MCU/SPI Interface 25PIN

  • Size: 2 inch

  • Resolution: 240*320

  • Interface: MCU-8/4-wire SPI

  • Driver IC: ST7789V

  • View Angle: IPS

  • Brightness: 400 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

2 inch lcd
2 inch lcd
2 inch lcd screen
2 inch lcd display
2 inch tft display
320x240 lcd
320x240 display

Overview of Z20001 240*320 2 Inch LCD Display Module MCU/SPI Interface 25PIN

1

Z20001 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 240*320 resolution. IPS (In-plane Switching) technique make this 2" LCD module have a wider view angle. This wholesale LCD display module is built-in ST7789V driver IC. This a-Si TFT LCD module come with 8-bit MCU/4-wire SPI interface, 400 cd/m² brightness.

2

 If you have special requirement, like drive IC interface, FPC, touch panel, backlight, etc, as a professional custom LCD display manufacturer, we can also customize for you.

3

As the leading China LCD module manufacturer, our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 2 inch LCD screen is smart watch, medical oximeter, cosmetic instrument, household appliance, translator, music player, smart home, industry, etc.

Specifications of 240*320 2 Inch LCD Display Module MCU/SPI Interface 25PIN


No.

Item

Specification

Unit

1

Display Size (Diagonal)

2.0

inch

2

Display Resolution

240 (H) × RGB × 320 (V)

pixels

3

Pixel Pitch

42.5 (H) × 127.5 (V)

um

4

LCM Outline Dimension

(Without FPC)

37.68 (W) × 51.32 (H) ×2.3 (T)

mm

5

LCD Outline Dimension

33.6 (W) × 43.6 (H) × 0.8 (T)

mm

6

LCD Active Area

30.6 (W) × 40.8 (H)

mm

7

View Direction (Gray Inversion)

FULL VIEW

-

8

Driver IC

ST7789V2-G4-A

-

9

Pixel Arrangement

RGB-Stripe

-

10

Display Mode

Normal Black

-

11

Pixel Driving Element

a-Si TFT

-

12

LCD Transmittance

Typ.: 4.5% Min: 3.8%

-

13

LCD Contrast Ratio

Typ.: 800 Min: 640

-

14

FPC Version

Z20001-FLP V1

-

15

Interface

8-bit MCU/SPI

-

16

Operating Temperature

-20°C~ 70°C

-

17

Storage Temperature

-30°C~ 80°C

-

18

Backlight Arrangement

LED/1 Series 3 Parallel (3 lights in total)

-

19

Luminance

TBD

nit

20

Weight

TBD

kg


Interface Definition Description of 240*320 2 Inch LCD Display Module MCU/SPI Interface 25PIN


PIN NO.

PIN DEF.

FUNCTION DESC.

1

GND

Ground

2

VDD

POWER SUPPLY(2.8V)

3

IOVDD

POWER SUPPLY(1.8V)

4

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

5-7

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

8

TE

Tearing Effect PIN

9

GND

Ground

10

RDX

Read enable in 8080 MCU parallel interface

11

WRX

Write enable in 8080 MCU parallel interface

12

DCK

Display data/command selection pin in parallel interface

13

CSX

Chip selection pin

14

SDA

SPI data (SDA) data input (MOSI)

15-22

D7-D0

DATA BUS

23

RES

LCM RESET PIN

24

IM1

LCM IM1 PIN

25

IM2

LCM IM2 PIN

RES voltage should be consistent with IOVDD voltage, or there probably is black screen fault when power on.
