Z101042 10.1 Inch IPS LCD Panel 1280*800 QVGA LVDS Interface 500 Nits

  • Size:10.1"

  • Resolution: 1280*800

  • Interface: LVDS

  • View Angle: IPS

  • Driver IC: EK79202B+EK79202B

  • Supply Type: Factory/Manufacturer

  • Certification:ISO9001,IATF16949,ROHS,REACH

ips tft manufacturers
ips tft manufacturers
tft lcd ips suppliers
ips lcd
lcd ips display
ips tft lcd display

Overview of Z101042 10.1 Inch IPS LCD Panel 1280*800 QVGA LVDS Interface 500 Nits

1

Z101042 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1280*800 resolution. IPS(In-plane Switching) technique make this 10.1" LCD Module have a wider view angle.This LCD display is built-in EK79202B+EK79202B driver IC.This a-Si TFT LCD come with LVDS interface.

2

If you have special requirement,like driver IC,interface,FPC,touch panel,backlight etc, we can also customize for you.

3

Our factory carry out ISO 9001:2015 and IATF16949: 2016 quality standard system strictly, all the lcd display passed ROHS, REACH Certification.

4

The 10.1" LCD Screen is wide used on laptop,tablet,kiosk, supermarket,menu board, dashboard, conference room, gaming, advertising, kiosk, audio, VR, AR,POS, medical, HMI, navigation, education etc.

General Specifications Z101042 10.1 Inch IPS LCD Panel 1280*800 QVGA LVDS Interface 500 Nits


No.

Item

Specification

Unit

1

Display Size (Diagonal)

10. 1

inch

2

Display Resolution

1280(H) × RGB × 800(V)

pixels

3

Pixel Pitch

56.5(H) × 169.5(V)


um


4

TLCM Outline Dimension

(Without FPC)


246.94(W) × 169.6 (H) ×4.4 (T)


mm

5

LCM Outline Dimension

224.02 (W) × 147.76 (H) × 2.6 (T)

mm

6

LCD Active Area

216.96(W) × 135.60(H)

mm

7

View Direction (Gray Inversion)

FULL VIEW


-

8

Driver IC

EK79202B+EK79202B


-

9

Pixel Arrangement

RGB-Stripe


-

10

Display Mode

Normal Black


-

11

Pixel driving Element

a-Si TFT


-

12

LCD Transmittance

Typ.: 5.5%


-

13

LCD Contrast Ratio

Typ.: 1000


-

14

FPC Version

/


-

15

Interface

LVDS


-

16

Operating Temperature

-20°C~ 70°C


-

17

Storage Temperature

-30°C~ 80°C


-

18

Backlight Arrangement

LED/6 Series 9 Parallel (54 lights in total)


-

19

Luminance

Typ.:500

nit

20

Weight

TBD

kg



Interface Definition Description Z101042 10.1 Inch IPS LCD Panel 1280*800 QVGA LVDS Interface 500 Nits


PIN NO.

PIN DEF.

FUNCTION DESC.

1

NC

No Connection

2-4

VDDIN

Power supply VDDIN=3.3V (Typ.)

5

NC

No Connection

6-7

GND

Ground

8

RIN0-

LVDS    Negative    data    signal(-)

9

RIN0+

LVDS    Positive    data    signal(+)

10

GND

Ground

11

RIN1-

LVDS    Negative    data    signal(-)

12

RIN1+

LVDS    Positive    data    signal(+)

13

GND

Ground

14

RIN2-

LVDS    Negative    data    signal(-)

15

RIN2+

LVDS    Positive    data    signal(+)

16

GND

Ground

17

LVDS_CLK-

LVDS    Negative    CLK    signal(-)

18

LVDS_CLK+

LVDS    Positive    CLK    signal(+)

19

GND

Ground

20

RIN3-

LVDS    Negative    data    signal(-)

21

RIN3+

LVDS    Positive    data    signal(+)

22

GND

Ground

23-24

NC

No Connection

25

GND

Ground

26-27

NC

No Connection

28

GND

Ground

29-30

NC

No Connection

31-33

LED-

POWER SUPPLY- FOR BACKLIGHT CATHODE

34-37

NC

No Connection

38-40

LED+

POWER SUPPLY- FOR BACKLIGHT ANODE

RESET voltage should be consistent with VDDI voltage, or there probably is black screen fault when power on.
