Z30070-ZC 3 Inch 480*854 TFT LCD Panel With Touch Screen 22PIN MIPI/I2C Interface

  • Size: 3 inch

  • Resolution: 480*854

  • LCD Interface: MIPI

  • Touch Interface: IIC

  • Touch Panel: Capacitive

  • Driver IC: ST7701S

  • Touch Controller: GT911

  • View Angle: IPS

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

touch screen 3 inch
touch screen 3 inch
3 inch 480 854 tft touch screen
3 inch touch screen 22pin
i2c 3 inch touch screen

Overview of Z30070-ZC 3 Inch 480*854 TFT LCD Panel With Touch Screen 22PIN MIPI/I2C Interface

1

Z30070-ZC is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with capacitive touch panel, QVGA 480*854. This TFT touch display is built-in ST7701S LCD driver IC and GT911 touch controller. This a-Si square TFT  LCD module come with MIPI and I2C interface. Multi-point touch.G+G structure.

2

If you have special requirement, like drive IC, interface, FPC, touch panel, backlight, brightness, color etc, as a custom LCD display manufacturer China, we can also customize for you.

3

Our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

This 3 inch LCD touch screen is widely used in medical oximeter, cosmetic instrument, household appliance, translator, music player, smart home, industry, infrared thermometer, hematometer, etc.

General Specifications 3 Inch 480*854 TFT LCD Panel with Touch Screen 22PIN MIPI/I2C Interface


No.

Item

Specification

Unit

1

Display Size (Diagonal)

3.0

inch

2

Display Resolution

480 (H) × RGB × 854 (V)

pixels

3

Pixel Pitch

26 (H) × 78 (V)

um

4

LCM Outline Dimension

(Without FPC)

42.70 (W) × 74.70 (H) × 2.45 (T)

mm

5

LCD Outline Dimension

40.33 (W) × 72.86 (H) × 1.0 (T)

mm

6

TLCM Outline Dimension

(Without FPC)

46.40 (W) × 78.574 (H) × 3.95 (T)

mm

7

LCD Active Area

37.44 (W) × 66.61 (H)

mm

8

View Direction (Gray Inversion)

FULL VIEW

-

9

Driver IC

ST7701S-G5

-

10

Pixel Arrangement

RGB-Stripe

-

11

Display Mode

Normal Black

-

12

Pixel driving Element

a-Si TFT

-

13

LCD Transmittance

Typ.: 3.5% Min: 3.1%

-

14

LCD Contrast Ratio

Typ.: 1000 Min: 800

-

15

FPC Version

Z30070-P22F-M V1

-

16

Interface

MIPI

-

17

Operating Temperature

-20°C~ 70°C

-

18

Storage Temperature

-30°C~ 80°C

-

19

Backlight Arrangement

LED/6 Series 1 Parallel (6 lights in total)

-

20

Luminance

TBD

nit

20

Weight

TBD

kg


Interface Definition Description 3 Inch 480*854 TFT LCD Panel with Touch Screen 22PIN MIPI/I2C Interface


2.1 LCM PIN

PIN NO.

PIN DEF.

FUNCTION DESC.

1-2

GND

Ground

3

D0N

Negative MIPI differential data input

4

D0P

Positive MIPI differential data input

5-6

GND

Ground

7

CLKN

Negative MIPI differential CLOCK input

8

CLKP

Positive MIPI differential CLOCK input

9

GND

Ground

10

D1N

Negative MIPI differential data input

11

D1P

Positive MIPI differential data input

12

RESET

LCM RESET PIN

13-14

GND

Ground

15

IOVCC

I/O POWER SUPPLY

16

VCC

POWER SUPPLY

17

GND

Ground

18

TE

Tearing Effect PIN

19

GND

Ground

20

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

21

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

22

GND

Ground

RESET voltage should be consistent with IOVCC voltage, or there probably is black screen fault when power on.


2.2 TP PIN

PIN NO.

PIN DEF.

FUNCTION DESC.

1

TP_VDD

TP POWER SUPPLY

2

TP_RST

TP Reset PIN (1.8V)

3

TP_INT

TP Interrupt PIN (1.8V)

4

TP_SCL

TP I2C clock (SCL) clock (SCLK)(1.8V)

5

TP_SDA

TP I2C data (SDA) data input (MOSI)(1.8V)

6

GND

Ground


Mechanical Drawing 3 Inch 480*854 TFT LCD Panel with Touch Screen 22PIN MIPI/I2C Interface


3.1 LCM


Mechanical Drawing 3 Inch 480*854 TFT LCD Panel with Touch Screen 22PIN MIPI/I2C Interface


3.2 TLCM


Mechanical Drawing 3 Inch 480*854 TFT LCD Panel with Touch Screen 22PIN MIPI/I2C Interface
