Z40063 Custom 4.0 Inch 320*480 TFT LCD Display Module SPI Interface IPS Panel ST7365P Controller

1

Display Size (Diagonal)

3.98

inch

2

Display Resolution

320(H） × RGB × 480（V）

pixels

3

Pixel Pitch

174(H）× 174（V）

um

4

CTP Outline Dimension

(Without FPC）

74.00 (W) ×142.00 (H) ×3.97 (T)

mm

5

LCD Outline Dimension

57.88 (W) × 89.92 (H) × 0.8 (T)

mm

6

LCD Active Area

55.68（W） ×83.52（H）

mm

7

View Direction (Gray Inversion)

FULL VIEW

-

8

Driver IC

ST7365P

-

9

Pixel Arrangement

RGB-Stripe

-

10

Display Mode

Normal Black

-

11

Pixel driving Element

a-Si TFT

-

12

LCD Transmittance

Typ.: 5.1%  Min:4.6%

-

13

LCD Contrast Ratio

Typ.: 1200  Min:1000

-

14

FPC Version

Z40063-P12-ZC1

-

15

Interface

SPI

-

16

Operating Temperature

-20°C~ 70°C

-

17

Storage Temperature

-30°C~ 80°C

-

18

Backlight Arrangement

LED/1 Series 8 Parallel (8 lights in total)

-

19

Luminance

Typ.:280

nit

20

Weight

TBD

kg

1

GND

Ground

2

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

3

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

4

VCC

POWER  SUPPLY

5-6

GND

Ground

7

D/C

SPI  Data/Command  Control  PIN

8

CS

Chip  selection  pin

9

SCL

SPI  clock (SCL)  clock  (SCLK)

10

SDA

SPI  data (SDA)  data  input (MOSI)

11

RESET

LCM  RESET  PIN

12

GND

Ground

RESET voltage should be consistent with VCC voltage, or there probably is black screen fault when power on.
