IPS TFT LCD Display

IPS TFT LCD Display

Size: 0.96" to 15.6"

Resolution: 80*160 to 1920*1200

Shape: 4:3, 16:9, round, square, bar

Interface: SPI, RGB, MCU, MIPI, LVDS, EDP

View direction: Full (IPS)

Touch screen: Support

Customization: Support

Size: 0.96" to 15.6"

Resolution: 80*160 to 1920*1200

Shape: 4:3, 16:9, round, square, bar

Interface: SPI, RGB, MCU, MIPI, LVDS, EDP

View direction: Full (IPS)

Touch screen: Support

Customization: Support

The IPS screen is a technology based on TFT, and its TFT display too.

1. It uses horizontal conversion technology to make the LCD screen more responsive and stable.

2. IPS LCD has a large view angle.

3. No matter which angle, you can enjoy the ideal picture with vivid, saturated and natural colors.


IPS means In-Plane Switching, it is a liquid crystal panel technology launched in 2001, it also called "Super TFT". IPS LCD display is featured for fast response, large view angle, true colors, environmental, touch without water marks, light weight and so on.

IPS TFT LCD Display Types


Size(inch)ResolutionModel No.Outline Dimension(mm)Active Area(mm)View AngleInterfaceLuminance(nits)Touch ScreenOP(℃)
0.9680*160Z1000313.5*27.95*1.5510.8*21.696IPS4-SPI300Support-20℃~70℃
1.28240*240Z1300635.6* 38.1*1.5632.4*32.4IPSMCU-8350Support-20℃~70℃
1.3240*240Z13001-P2426.17*29.22*1.5323.40*23.40IPSMCU-8500Support-20℃~70℃
1.3240*240Z1300126.17*29.22*1.5323.40*23.40IPS4-SPI500Support-20℃~70℃
1.3240*240Z1300226.17*29.22*1.5323.40*23.40IPS4-SPI500Support-20℃~70℃
1.3240*240Z1300426.17*29.22*1.523.40*23.40IPSSPI450Support-20℃~70℃
1.3360*360Z1300535.24 *37.67 *2.1532.94*32.94IPSSPI700Support-20℃~70℃
1.46360*360Z1460139.3*40.96*1.632.94*32.94IPSSPI300Support-20℃~70℃
1.47172*320Z14700119.65*36.76*1.5617.65*32.83IPSSPI350Support-20℃~70℃
1.54240*240Z1500231.52*33.72*1.9427.72*27.72IPSMCU-8/ 16350Support-20℃~70℃
1.5320*320Z1500431.52*33.72*1.9 (T)27.744*27.744IPSMIPI600Support-20℃~70℃
1.47 170*320   Z1500719.65*36.76*1.617.65*32.83IPSSPI600Support-20℃~70℃
1.54240*240Z15400131.50*35.0*1.9127.72*27.72IPS8 -MCU/4-SPI300Support-20℃~70℃
1.6400*400Z1600342.9*45.89*1.6039.84*39.84IPSSPI350Support-20℃~70℃
1.69240*280Z16900130.07*37.43*1.627.97*32.63IPSSPI450Support-20℃~70℃
1.69240*280Z1700230.07*37.43*1.927.97*32.63IPSSPI600Support-20℃~70℃
1.77128*160Z1800134.00*45.80*2.4528.03*35.04IPSMCU-8
Support-20℃~70℃
2.0240*320Z2000137.68*51.32*2.3030.60*40.80IPSMCU-8/4-SPI
Support-20℃~70℃
2.0170*320   Z2000525.10*49.47*1.90 22.695*42.72IPSMCU600Support-20℃~70℃
2. 1480*480Z2100156.18*59.71*2.353.28*53.28IPSSPI+RGB350Support-20℃~70℃
2. 1480*480Z2100256.18*59.71*2.2653.28*53.28IPSMIPI380Support-20℃~70℃
2.4240*320Z2400640.52*57.00*2.1536.72*48.76IPSMCU
Support-20℃~70℃
2.4240*320Z2400840.52*57.00*2.1536.72*48.76IPSMIPI
Support-20℃~70℃
2.7960*240Z2700167.5*39.1*2.4355.8*33.06TNSPI300Support-20℃~70℃
2.73 320*320Z2700253.54*58.74*2.54 48.96*48.96IPSMIPI
Support-20℃~70℃
2.8240*320Z2800147.40*65.95*2.2543.20*57.60IPSMCU
Support-20℃~70℃
2.8240*320Z2800550*69.20*2.3043.20*57.60IPSMCU/SPI700Support-20℃~70℃
2.8480*480Z2800773.03*76.48*2.3070.128*70.128IPSSPI+RGB300Support-20℃~70℃
3.0480*854Z3001042.70*74.70*2.5037.44*66.61IPSSPI+RGB400Support-20℃~70℃
3.0480*854Z3003242.70*74.70*2.5037.44*66.61IPSMIPI/SPI+RGB500Support-20℃~70℃
3.0480*854Z3004340.64*74.68*1.7437.44*66.61IPSMIPI350Support-20℃~70℃
3.0480*854Z3005242.70*74.70*2.5037.44*66.61IPSSPI+RGB400Support-20℃~70℃
3.0480*854Z3005440.64*74.68*2.3437.44*66.61IPSMIPI550Support-20℃~70℃
3.0480*854Z3005642.70*74.70*2.5037.44*66.61IPSMIPI
Support-20℃~70℃
3.0480*854Z3006042.70*74.70*2.5037.44*66.61IPSMIPI400Support-20℃~70℃
3.0480*854Z3007440.64*74.68*1.7437.44*66.61IPSMIPI480Support-20℃~70℃
3.0480*854Z3007842.70*74.70*2.4537.44*66.61IPSSPI+RGB500Support-20℃~70℃
3.0480*854Z3007942.70*74.70*2.5037.44*66.61IPSMIPI380Support-20℃~70℃
3.0480*854Z3008240.64*74.68*1.7437.44*66.61IPSMIPI500Support-20℃~70℃
3.0480*854Z3008340.64*74.68*2.3437.44*66.61IPSMIPI500Support-20℃~70℃
3.4480*480Z3400165.72*69.64*2.4560.48*60.48IPSSPI+RGB/MIPI500Support-20℃~70℃
3.4800*800Z3400594.90*96.95*1.1687.60*87.60IPSSPI+RGB600Support-20℃~70℃
3.5320*240Z3500876.78*63.74*3.2070.08*52.56IPSRGB
Support-20℃~70℃
3.5320*480Z3501353.76*82.39*2.2348.96*73.44IPSMIPI330Support-20℃~70℃
3.5320*480Z35013-P1253.76*82.39*2.448.96*73.44IPSSPI330Support-20℃~70℃
3.5640*480Z3510176.84*63.84*3.2770.08*52.56IPSRGB450Support-20℃~70℃
3.5320*480Z3501853.76*82.39*2.2348.96*73.44IPSSPI300Support-30℃~85℃
3.5480*800Z35030-P2550.1*85.8 *2.145.36*75.6IPSMIPI300Support-20℃~70℃
3.5480*800Z35030-P4050.1*85.8*2.145.36*75.6IPSSPI+RGB300Support-20℃~70℃
3.71240*960Z3700125.3*98.89*1.6522.86*91.44IPSSPI+RGB300Support-20℃~70℃
3.97480*800Z4003255.44*96.15*1.7151.84*86.40IPSSPI+RGB
Support-20℃~70℃
3.97480*800Z4003555.44*96.15*1.7151.84*86.40IPSMIPI
Support-20℃~70℃
3.95720*720Z4005074.83*78.98*2.1471.93*71.93IPSMIPI
Support-20℃~70℃
3.97480*800Z4004555.44*96.15*1.7151.84*86.40IPSMIPI320Support-20℃~70℃
3.97480*800Z4004657.14*96.85*2.1551.84*86.40IPSMIPI400Support-20℃~70℃
3.95480*480Z4004874.83*78.68*2.1571.856*70.176IPSMIPI/SPI+RGB
Support-20℃~70℃
4.0720*720Z40054105.60*109.87*2.22101.52*101.52IPSMIPI500Support-20℃~70℃
3.98320*480Z4005960.88*94.57*2.3255.68*83.82IPSSPI250Support-20℃~70℃
4.3480*272Z43014105.46*67.16*2.7595.04*53.86IPSRGB500Support-20℃~70℃
4.3480*272Z43016105.46*67.16*2.7595.04*53.86IPSRGB500Support-20℃~70℃
4.3480*272Z43017105.46*67.16*2.7595.04*53.86IPSRGB500Support-20℃~70℃
4.3480*272Z43018105.46*67.16*2.7595.04*53.86IPSRGB500Support-20℃~70℃
4.3480*272Z43021105.46*67.16*2.7595.04*53.86IPSRGB500Support-20℃~70℃
4.3480*800Z4302760.46*103.65*1.8656.16*93.70IPSSPI+RGB/MIPI500Support-20℃~70℃
4.3480*272HXH43029105.46*67.16*2.7595.04*53.86IPSRGB600Support-20℃~70℃
4.3800*480Z43080105.46*67.1*3.095.04*53.86IPSRGB1000Support-20℃~70℃
4.5480*854Z4505858.69*107.48*2.0355.44*98.64IPSMIPI
Support-20℃~70℃
4.5480*854Z4505958.75*107.4*1.955.44*98.64IPSMIPI
Support-20℃~70℃
4.6320*960Z4600941.568*118.804*2.536.768*110.304IPSMIPI450Support-20℃~70℃
5.0480*854Z4939966.40*120.05*2.2561.63*109.65IPSSPI+RGB530Support-20℃~70℃
5.0480*854Z4941666.40*120.05*2.2561.63*109.65IPSMIPI600Support-20℃~70℃
5.0480*854DM4941766.3*120.3*2.0362.06*110.4IPSMIPI400Support-20℃~70℃
5.0720*1280Z4942065.89*119.91*1.6563.72*113.28IPSMIPI450Support-20℃~70℃
5.0720*1280Z4942167.56*122.35*3.2862.60*111.08IPSMIPI450Support-20℃~70℃
5.01080*1080Z50006136.531*132.2*1.98127.008127.008IPSMIPI500Support-20℃~70℃
5.0800*480Z50070120.7*75.8*3.0108*64.8IPSRGB350Support-20℃~70℃
5.5720*1280Z5529071.00*130.20*1.6768.04*120.96IPSMIPI350Support-20℃~70℃
5.5720*1280Z5529271.00*130.20*1.6768.04*120.96IPSMIPI420Support-20℃~70℃
5.7320*240Z57003127*98.43*8.2115.2*86.4IPSMIPI1300Support-20℃~70℃
5.7640*480Z57011127*98.43*8.2115.2*86.4IPSMIPI1300Support-20℃~70℃
6.0720*1480Z6003670.8*145.5 *2.2566.744*137.196IPSMIPI350Support-20℃~70℃
6.86480*1280Z68600665.82*171.79*2.6060.22*160.59IPSMIPI500Support-20℃~70℃
6.9720*1440Z6900183.75*169.37*2.3578.02*156.04IPSMIPI450Support-20℃~70℃
6.95600*1024CD0695025LCD95*163.2*2.689.28*152.37IPSMIPI330Support-20℃~70℃
6.95600*1024CD069503995*163.15*2.589.28*152.37IPSMIPI400Support-20℃~70℃
7.0600*1024Z7000195*163.15*2.589.28*152.37IPSMIPI500Support-20℃~70℃
7.0720*1280Z7001091.44*165.9186.94*154.56IPSMIPI
Support-20℃~70℃
7.01024*600Z70017163.7*96.9*2.59154.21*85.92IPSMIPI500Support-20℃~70℃
7.0600*1024Z7002795*163.2*2.689.28*152.37IPSMIPI400Support-20℃~70℃
7.01024*600Z70048163.70*96.9*2.6154.21*85.92IPSRGB
Support-20℃~70℃
7.01024*600Z70049163.70*96.9*2.6154.21*85.92IPSMIPI
Support-20℃~70℃
7.01024*600Z70069163.7*96.9 *2.59154.21*85.92IPSRGB700Support-20℃~70℃
7.01024*600Z70070161*107*3.35149.76*93.6IPSMIPI
Support-20℃~70℃
6.95600*1024Z7007294.90*163.10*2.5389.28*152.37IPSMIPI350Support-10℃~50℃
7.01024*600Z70078163.7*96.9*2.55154.21*85.92IPSMIPI500Support-20℃~70℃
7.0720*1280Z7007990.5*163.8*2.6587.264*155.136IPSMIPI
Support-10℃~60℃
7.0600*1024HL070WSCAV01994.94*163.24*2.5189.28*152.37IPSMIPI350Support-20℃~70℃
7.0720*1280Z7008591.44*165.9186.94*154.56IPSMIPI370Support-20℃~70℃
7.0800*480Z70086165*100*5.7 153.840*85.63IPSRGB350Support-20°C~70°C
7.0800*1280Z7008899.65*60.85*2.4094.20*150.72IPSMIPI1000Support-30°C~85°C
7.01200*1920Z7010299.81*161.66 *2. 1894.5*151.2IPSMIPI1000Support-20℃~70℃
7.01024*600Z70103164.86*99.96*3.6154.21*85.92IPSRGB1000Support-20℃~70℃
7.84400*1280Z78400167.14*205.12*4.5059.40*190.08IPSMIPI
Support-20℃~70℃
8.0800*1280Z80008-SPM288114.60*184.10*2.61107.64*172.72IPSMIPI380Support-20℃~70℃
8.0800*1280Z80019114.66*184.16*2.65107.64*172.224IPSMIPI580Support-20℃~70℃
8.01200*1920Z80035-P39122.44*183.67*2.62107.64*172.22IPSMIPI800Support-20℃~70℃
8.01280*800Z80036181.85*119.30*2.40172.22*107.64IPSLVDS350Support-20℃~70℃
8.01280*720Z80051192.80*116.90*6.40176.64*99.36IPSLVDS800Support-20℃~70℃
8.8480*1920Z8800164.10*231.20*4.7054.72*218.88IPSMIPI550Support-20℃~70℃
8.9800*1280PJ8901B01125.48*202.90 *2.6119.28*190.85IPSMIPI350Support-20℃~70℃
9.0800*1280Z90006125.48*202.90*2.60119.28*190.85IPSMIPI500Support-20℃~70℃
9.0800*1280Z90010125.48*202.90*2.60119.28*190.85IPSMIPI300Support-20℃~70℃
9.0800*1280Z90014-SPM308H125.48*202.90*2.6119.28*190.85IPSMIPI350Support-20℃~70℃
9.0800*1280Z90018125.48*202.90*2.55119.28*190.84IPSMIPI350Support-20℃~70℃
9.0800*1280Z90019125.5*202.94*2.6119.28*190.84IPSMIPI350Support-20℃~70℃
9.01024*600Z90080201.7*126.5*5196.906*114.158IPSLVDS400Support-20℃~70℃
10. 11200*1920Z101017143.10*228.60*2.6135.36*216.58IPSMIPI400Support-20℃~70℃
10. 1800*1280Z101020143.1*228.6*2.6135.36*216.58IPSMIPI300Support-20℃~70℃
10. 1800*1280Z101024143.1*228.6*2.6135.36*216.58IPSMIPI350Support-20℃~70℃
10. 1800*1280Z101027143*228.6*2.63135.36*216.58IPSMIPI350Support-20℃~70℃
10.361200*2000Z101028140.36*234.63*1.9135.36*225.60IPSMIPI300Support-15℃~60℃
10. 11024*600Z101060-P50235*143*5.2222.72*125.28IPSRGB450Support-20℃~70℃



Size(inch)ResolutionModel No.Outline Dimension(mm)Active Area(mm)View AngleInterfaceLuminance(nits)Touch ScreenOP(℃)
10.11280*800Z101042224.02*147.76*2.6216.96*135.60IPSLVDS500Support-20℃~70℃
10.11280*800Z101044229.46* 149.10*4.82216.96*135.60IPSLVDS900Support-20℃~70℃
10. 11920*1200Z10100-P45228.5*149*4.55216.81*135.5IPSLVDS1000Support-20℃~70℃
10.251920*720Z103002265.2*109.2*9.35243.648*91.368IPSLVDS600Support-20℃~70℃
10.4800*600Z104001228.5*175.5211.2x158.4TNRGB350Support-20℃~70℃
11.61920*1080Z116001263.4 *167.25* 2.6256.32*144. 18IPSLVDS
Support-20℃~70℃
12.1
1920*1080Z121001283*185.1*7.15261.120*163.2IPSLVDS1500Support-20℃~70℃
12.31920*720Z123001299.5*123*5.92292.032*109.512IPSLVDS1300Support-20℃~70℃
12.31920*720Z123003321.6*138.8*6.15292.032*109.51
2		IPSLVDS1000Support-20℃~70℃
13.31920*1080Z133001305.2 *187.9 *2.6293.76 *165.24IPSEDP500Support-20℃~70℃
14.03860*2160Z140001315.01*186.14 *2.2309.31*173.99IPSEDP500Support-20℃~70℃
15.01024*768Z150001326.50* 253.5 *11. 13304.
128*228.096		TNLVDS500Support-20℃~70℃
15.61920*1080Z156003359.5*223.8*3.2344.23*196.54IPSEDP220Support-20℃~70℃
17.01280*1024Z170001358.5*296.5*10.3337.92*270.34TNLVDS250Support-20℃~70℃
17.31920*1080Z173001403*240*12.5381.888*214.812TNLVDS400Support-20℃~70℃
18.51920*1080Z185001430.6*254.6*9.8408.96*230.04IPSLVDS1000Support-20℃~70℃
21.51920*1080Z215001495.6*292.2*10.7476.064*267.786IPSLVDS250Support-20℃~70℃


Contact Us

Zhunyi Technology pays attention to the quality and service. Welcome to visit us and join hands for a prosperous future.

Contact Info
Email Us
sales@zhunyikeji.com
Call us
+86-0755-2790-3035
Address
2nd, 3rd and 8th Floor, Dongshan plant, Huafeng First Science Park, Sanwei, Bao'an District, Shenzhen, China
Request A Quote
Zhunyi TFT LCD Module Insight & Blog
08-03 2024
Life Expectancy of TFT LCD Panels Life Expectancy of TFT LCD Panels
07-30 2024
Medical and Diagnostic LCD Displays Medical and Diagnostic LCD Displays
07-26 2024
Resolution and Pixel Density in LCDs Resolution and Pixel Density in LCDs
Products
Applications
Resources
Quick Links
Copyright © Shenzhen Zhunyi Technology Co., Ltd. All Rights Reserved.
Sitemap Privacy Policy
We use cookies to offer you a better browsing experience, analyze site traffic and personalize content. By using this site, you agree to our use of cookies. Visit our cookie policy to learn more.
Reject Accept
