Z70085 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View

  • Size: 7 inch

  • Resolution: 720*1280

  • Active Area: 89.28*152.37 mm

  • Interface: MIPI

  • View Angle: IPS

  • Brightness: 370 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

Request A Quote
ili9881c a company
ili9881c a company
ili9881c datasheet a bulk
ili9881c a wholesale
ili9881c datasheet bulk
ili9881c company
ili9881c bulk
ili9881c manufacturer
ili9881c datasheet wholesale
ili9881c
ili9881c datasheet
ili9881c datasheet company
ili9881c datasheet manufacturer
ili9881c wholesale

Overview of Z70085 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View

1

Z70085 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 720*1280 resolution. IPS (In-plane Switching) technique make this 7" LCD module have a wider view angle. This LCD display in China is built-in ILI9881C driver IC. This a-Si TFT LCD module come with MIPI interface, 370cd/m² brightness.

2

If you have special requirements, like drive IC, interface, FPC, touch panel, brightness, color, backlight, touch panel, etc, we can provide China TFT LCD display module for you.

3

Our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 7 inch China TFT touch screen is widely used in Medical, visual doorbell, Vending, learning mechine, ventilator, oscilloscope, kitchen, household appliance, QRcode scanner, smart home, industry, handheld, outdoor, HMI, E-bike, Vehicle, projector, 3D printer, audio device, robot, electric scale, navigation, elevator advertising, etc.

Specifications of 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View


No.

Item

Specification

Unit

1

Display Size (Diagonal)

7.0

inch

2

Display Resolution

720 (H) × RGB × 1280 (V)

pixels

3

Pixel Pitch

120.75 (H) × 120.75 (V）

um

4

LCM Outline Dimension

(Without FPC）

91.44 (W) × 165.91 (H) ×2.35 (T)

mm

5

LCD Outline Dimension

89.94 (W) × 162.56 (H) × 0.7 (T)

mm

6

CG Outline Dimension

(Without FPC）

97.80 (W) × 235.35 (H) ×4.15 (T)

mm

7

LCD Active Area

86.94 (W) × 154.56 (H)

mm

8

View Direction (Gray Inversion)

FULL VIEW

-

9

Driver IC

ILI9881C

-

10

Pixel Arrangement

RGB-Stripe

-

11

Display Mode

Normal Black

-

12

Pixel driving Element

a-Si TFT

-

13

LCD Transmittance

Typ.: 4.0%

-

14

LCD Contrast Ratio

Typ.: 800 Min: 640

-

15

FPC Version

Z70010-P40F-I

-

16

Interface

MIPI

-

17

TP Interface

I2C


18

Operating Temperature

-20°C~ 60°C

-

19

Storage Temperature

-30°C~ 70°C

-

20

Backlight Arrangement

LED/7 Series 3 Parallel (21 lights in total)

-

21

Luminance (LCM）

370 TYP

nit

22

Weight

TBD

kg


Interface Definition Description of 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View


PIN NO.

PIN DEF.

FUNCTION DESC.

1-2

VCI

POWER SUPPLY (3.3V）

3-4

IOVCC

I/O POWER SUPPLY (1.8V）

5

RESET

LCM RESET PIN

6

TE

Tearing Effect PIN

7

GND

Ground

8

MIPI_0N

Negative MIPI differential data input

9

MIPI_0P

Positive MIPI differential data input

10

GND

Ground

11

MIPI_1N

Negative MIPI differential data input

12

MIPI_1P

Positive MIPI differential data input

13

GND

Ground

14

MIPI_CKN

Negative MIPI differential CLOCK input

15

MIPI_CKP

Positive MIPI differential CLOCK input

16

GND

Ground

17

MIPI_2N

Negative MIPI differential data input

18

MIPI_2P

Positive MIPI differential data input

19

GND

Ground

20

MIPI_3N

Negative MIPI differential data input

21

MIPI_3P

Positive MIPI differential data input

22

GND

Ground

22-24

NC

No Connection

25

GND

Ground

26-29

NC

No Connection

30

GND

Ground

31-32

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

33-38

NC

No Connection

39-40

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

RESET voltage should be consistent with IOVCC voltage, or there probably is black screen fault when power on.


Mechanical Drawing of 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View


Mechanical Drawing of 7 Inch LCD Module 720*1280 ILI9881C Driver IC MIPI Interface IPS View
