DM49417 5 Inch LCD Screen 480*854 TFT Type MIPI Interface JD9161Z-JN Controller

  • Size: 5 inch

  • Resolution: 480*854

  • Active Area: 62.06*110.4mm

  • Interface: MIPI

  • View Angle: IPS

  • Brightness: 400 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

5 inch lcd screen
5 inch lcd screen
5 inch tft lcd screen
5
5
5 inch lcd screen wholesale
5 inch tft lcd screen wholesale
5
5
5 inch lcd screen manufacturer
5 inch tft lcd screen manufacturer
5
5

Overview of DM49417 5 Inch LCD Screen 480*854 TFT Type MIPI Interface JD9161Z-JN Controller

1

DM49417 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 480*854 resolution. IPS (In-plane Switching) technique make this 5" LCD module have a wider view angle. This square IPS LCD panel is built-in JD9161Z-JN driver IC. This a-Si TFT LCD module come with MIPI interface, 400cd/m² brightness.

2

If you have special requirements, like drive IC interface, FPC, touch panel, backlight, etc, we can provide custom shaped lcd display for you.

3

As a square LCD screen manufacturer, our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 5 inch LCD screen is widely used in Medical, visual doorbell, E-wallet, POS, game player, cosmetic instrument, household appliance, QRcode scanner, smart home, industry, handheld, outdoor, HMI, E-bike, Vehicle, etc.

Specifications of 5 Inch LCD Screen 480*854 TFT Type MIPI Interface JD9161Z-JN Controller


No.

Item

Specification

Unit

1

Display Size (Diagonal)

4.95

inch

2

Display Resolution

480 (H) × RGB × 854 (V)

pixels

3

Pixel Pitch

128.4 (H) × 128.4 (V)

um

4

LCM Outline Dimension

(Without FPC)

66.3 (W) ×120.3 (H) ×2.03 (T)

mm

5

LCD Outline Dimension

64.46 (W) × 116.8 (H) × 0.8 (T)

mm

6

LCD Active Area

62.06 (W) ×110.4 (H)

mm

7

View Direction (Gray Inversion)

FULL VIEW

-

8

Driver IC

JD9161Z-JN

-

9

Pixel Arrangement

RGB-Stripe

-

10

Display Mode

Normal Black

-

11

Pixel driving Element

a-Si TFT

-

12

LCD Transmittance

Typ.: 4.47%

-

13

LCD Contrast Ratio

Typ.: 800 Min: 600

-

14

FPC Version

DM49417-P40W V1

-

15

Interface

MIPI

-

16

Operating Temperature

-20°C~ 70°C

-

17

Storage Temperature

-30°C~ 80°C

-

18

Backlight Arrangement

LED/6 Series 2 Parallel (12 lights in total)

-

19

Luminance

520

nit

20

Weight

0.035

kg


Interface Definition Description of 5 Inch LCD Screen 480*854 TFT Type MIPI Interface JD9161Z-JN Controller


PIN NO.PIN DEF.FUNCTION DESC.
1LPTEServes TE (Tearing Effect) PIN
44960GNDGround
4D0PPositive MIPI differential data input
5D0NNegative MIPI differential data input
6GNDGround
7CLKPPositive MIPI differential CLOCK input
8CLKNNegative MIPI differential CLOCK input
9GNDGround
10D1PPositive MIPI differential data input
11D1NNegative MIPI differential data input
12GNDGround
13RSTReset PIN
14IOVCCI/O POWER SUPPLY (1.8V)
15NCNo Connection
16VCCPOWER SUPPLY (2.8/3.3V)
17CTP-EINTTP Interrupt PIN
18CTP-RSTTP Reset PIN
19CTP-SCLTP I2C clock (SCL) clock (SCLK)
20CTP-SDATP I2C data (SDA) data input (MOSI)
21CTP-VDDTP Input Power voltage (2.8/3.3V)
22NCNo Connection
23GNDGround
24NCNo Connection
25-26LEDKPOWER SUPPLY- FOR BACKLIGHT CATHODE
27NCNo Connection
28-29LEDAPOWER SUPPLY+ FOR BACKLIGHT ANODE
30NCNo Connection
RESET voltage should be consistent with VDDI voltage, or there probably is black screen fault when power on.
