Z13008 1.28 inch 240x240 SPI Interface Circular LCD Screen Display GC9A01 IC

  • Size: 1.28"

  • Resolution: 240*240

  • LCD Interface: SPI

  • Driver IC: GC9A01

  • View Angle: IPS

  • Supply Type: Factory/Manufacturer

  • Certification:ISO9001,IATF16949,ROHS,REACH


display round
display round
round display module
round display screen
round screen
screen round

Overview of Z13008 1.28 inch 240x240 SPI Interface Circular LCD Screen Display GC9A01 IC

1

Z13008 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 240*240 resolution. IPS(In-plane Switching) technique make this 1.28" LCD module have a wider view angle.This a-Si TFT LCD come with SPI interface.The display built-in GC9A01 driver IC.

2

If you have special requirement,like driver IC,interface,FPC,touch panel,backlight etc, we can customize for you.

3

Our factory carry out ISO 9001:2015 and IATF16949: 2016 quality standard system strictly, all the lcd display passed ROHS, REACH Certification.

4

The 1.28" round LCD panel is widely used on dashboard, VR Goggles, medical, Gauges, scales, meter, wearables, home appliances, thermostat, home control, rotary switch,knob etc.

General Specifications Z13008 1.28 inch 240x240 SPI Interface Circular LCD Screen Display GC9A01 IC


No.

Item

Specification

Unit

1

Display Size (Diagonal)

1.3

inch

2

Display Resolution

240(H) × RGB × 240  (V)

pixels

3

Pixel Pitch


-


um


4

LCM Outline Dimension

(Without FPC)


35.6 (W) ×37.74 (H) ×1.6 (T)


mm

5

LCD Outline Dimension

-

mm

6

LCD Active Area

32.4  (W) ×32.4  (H)

mm

7

View Direction (Gray Inversion)

FULL VIEW


-

8

Driver IC

GC9A01


-

9

Pixel Arrangement

RGB-Stripe


-

10

Display Mode

Normal Black


-

11

Pixel driving Element

a-Si TFT


-

12

LCD Transmittance

Typ.: 4.65%    Min:4. 18%


-

13

LCD Contrast Ratio

Typ.: 800    Min:640


-

14

FPC Version


Z13008 V1


-

15

Interface

4LINE-SPI


-

16

Operating Temperature

-20°C~ 70°C


-

17

Storage Temperature

-30°C~ 80°C


-

18

Backlight Arrangement

LED/2Parallel (2 lights in total)


-

19

Luminance

350

nit

20

Weight

0.003

g
