Z70048 7 Inch TFT Display Module 1024*600 50PIN RGB Interface

  • Size: 7 inch

  • Resolution: 1024*600

  • Active Area: 154.21*85.92mm

  • Interface: RGB

  • View Angle: IPS

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

lcd tft 7
lcd tft 7
7 inch 50 pin lcd display
50 pin lcd
50 pin lcd display
7 inch display module
lcd tft 7 wholesale
7 inch 50 pin lcd display wholesale
50 pin lcd wholesale
50 pin lcd display wholesale
7 inch display module wholesale
lcd tft 7 manufacturer
7 inch 50 pin lcd display manufacturer
50 pin lcd manufacturer

Overview of Z70048 7 Inch TFT Display Module 1024*600 50PIN RGB Interface

1

Z70048 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1024*600 resolution. IPS (In-plane Switching) technique make this 7" LCD module have a wider view angle. This LCD display is built-in EK79001H driver IC. This a-Si TFT LCD module come with RGB interface.

2

If you have special requirements, like drive IC interface, FPC, touch panel, brightness, color, backlight, etc, we can provide China TFT LCD display module for you.

3

As a China LCD module manufacturer, our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The horizontal 7 inch China TFT touch screen is widely used in Medical, visual doorbell, Vending, learning mechine, ventilator, oscilloscope, kitchen, household appliance, QRcode scanner, smart home, industry, handheld, outdoor, HMI, E-bike, Vehicle, projector, 3D printer, audio device, robot, electric scale, navigation, elevator advertising, etc.

Specifications of 7 Inch TFT Display Module 1024*600 50PIN RGB Interface


Item

Main Display

Unit

Number of Pixels

1024 * RGB * 600

Pixel

LCM Outline Dimension

163.70 (W) * 96.9 (H) * 2.59 (T)

mm

LCD Outline Dimension

162.20 (W) * 95.70 (H) * 1.0 (T)

mm

Active Area

154.21 (W) * 85.92 (H)

mm

Pixel Pitch

0.0502 (W) * 0.1432 (H)

mm

Display Mode

Normally Black


Pixel Arrangement

RGB vertical stripe


Viewing Direction

Free


Color Configuration

RGB


LCD Transmittance

Typ: 5.0%; Min: 4.8%


LCD Contrast Ratio

Typ: 800


FPC Version

Z70048-P50 V1


Interface

RGB


Operating Temperature

-20℃ ~ 70℃


Storage Temperature

-30℃ ~ 80℃


Backlight Arrangement

LED / 3series 8 parallel


Luminance

-


Weight

-



LCM-Pin Assignments of 7 Inch TFT Display Module 1024*600 50PIN RGB Interface


Pin NO.

PIN DEF.

FUNCTION DESC.

1

LED-A

POWER SUPPLY+ FOR BACKLIGHT

2

LED-A

POWER SUPPLY+ FOR BACKLIGHT

3

LED-K

POWER SUPPLY- FOR BACKLIGHT CATHODE

4

LED-K

POWER SUPPLY- FOR BACKLIGHT CATHODE

5

GND

Ground

6

VCOM

Common Voltage

7

VDD

Power for Digital Circuit (3.3V)

8

MODE

DE / HV mode select for LVDS mode.

9

DE

Data Enable

10

VS

Vertical synchronize Signal

11

HS

Horizontal synchronize Signal

12-19

B7-B0

Data bus

20-27

G7-G0

Data bus

28-35

R7-R0

Data bus

36

GND

Ground

37

DCLK

Pixel Clock

38

GND

Ground

39

SHLR

Source Right or Left sequence

40

UPDN

Gate Up or Down scan control

41

VGL

Gate OFF Voltage (-6V)

42

VGH

Gate ON Voltage (18V)

43

AVDD

Power for Analog Circuit (9.6V)

44

RESET

Global reset pin (3.3V)

45

NC

NC

46

VCOM

Common Voltage

47

DITHB

Dithering Function

48

GND

Ground

49

NC

NC

50

NC

NC


Mechanical Drawing of 7 Inch TFT Display Module 1024*600 50PIN RGB Interface
