Z90019 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface

  • Size: 9 inch

  • Resolution: 800*1280

  • Active Area: 119.28*190.85

  • Interface: MIPI

  • View Angle: IPS

  • Brightness: 350 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

Request A Quote
lcd display panel
lcd display panel
lcd display module
lcd module
lcd screen module
lcd module display
lcd screen panel
lcm display module
lcm liquid crystal module
liquid crystal display panel
liquid crystal display module

Overview of Z90019 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface

1

Z90019 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 800*1280 resolution. IPS (In-plane Switching) technique make this 9" LCD module have a wider view angle. This LCD display is built-in JD9365DA-H3 driver IC. This a-Si TFT LCD module come with MIPI interface, 350cd/m² brightness.

2

If you have special requirements, like drive IC, interface, FPC, touch panel, brightness, color, backlight, touch panel, etc, we can also customize for you.

3

Our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 9 inch LCD screen is widely used in Medical, visual doorbell, vending, learning mechine, ventilator, oscilloscope, kitchen, household appliance, smart home, industry, handheld, outdoor, E-bike, Vehicle, projector, 3D printer, audio device, robot, electric scale, navigation, dashboard, elevator advertising, laptop, HMI, education, etc.

Specifications of 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface



No.

Item

Specification

Unit

1

Display Size (Diagonal)

9.0

inch

2

Display Resolution

800 (H) × RGB × 1280 (V)

pixels

3

Pixel Pitch

149.1 (H) × 149.1 (V）

um

4

LCM Outline Dimension

(Without FPC）

125.5 (W) × 202.94 (H) × 2.6 (T)

mm

5

LCD Outline Dimension

123.68 (W) × 200 (H) × 0.8 (T)

mm

6

LCD Active Area

119.28 (W) × 190.84 (H）

mm

7

View Direction (Gray Inversion)

FULL VIEW

-

8

Driver IC

JD9365DA-H3

-

9

Pixel Arrangement

RGB-Stripe

-

10

Display Mode

Normal Black

-

11

Pixel driving Element

a-Si TFT

-

12

LCD Transmittance

Typ.: 4.8% Min: 4.2%

-

13

LCD Contrast Ratio

Typ.: 1000

-

14

FPC Version

Z90019-P40H V3

-

15

Interface

MIPI

-

16

Operating Temperature

-20°C~ 70°C

-

17

Storage Temperature

-30°C~ 80°C

-

18

Backlight Arrangement

LED/5 Series 6 Parallel (30 lights in total)

-

19

Luminance

350

nit

20

Weight

0.130

kg



Interface Definition Description of 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface


PIN NO.PIN DEF.FUNCTION DESC.
1VDDIOI/O POWER SUPPLY (1.8V）
2-3VDDPOWER SUPPLY (3.3V）
4GNDGround
5RESETLCM RESET PIN (1.8V)
6NCNo Connection
7GNDGround
8MIPI_D0NNegative MIPI differential data input
9MIPI_D0PPositive MIPI differential data input
10GNDGround
11MIPI_D1NNegative MIPI differential data input
12MIPI_D1PPositive MIPI differential data input
13GNDGround
14MIPI_CLKNNegative MIPI differential CLOCK input
15MIPI_CLKPPositive MIPI differential CLOCK input
16GNDGround
17MIPI_D2NNegative MIPI differential data input
18MIPI_D2PPositive MIPI differential data input
19GNDGround
20MIPI_D3NNegative MIPI differential data input
21MIPI_D3PPositive MIPI differential data input
22GNDGround
23NCNo Connection
24TP_VDDTP POWER SUPPLY (2.8V）
25TP_GNDGround
26TP_SCLTP I2C clock (SCL) clock (SCLK)(1.8V)
27TP_SDATP I2C data (SDA) data input (MOSI)(1.8V)
28TP_INTTP Interrupt PIN (1.8V)
29TP_RSTTP RESET PIN (1.8V)
30GNDGround
31-32VLEDKPOWER SUPPLY- FOR BACKLIGHT CATHODE
33ID1_GNDLCM ID PIN
34ID2_1.8VLCM ID PIN
35-38NCNo Connection
39-40VLEDAPOWER SUPPLY- FOR BACKLIGHT ANODE
RESET voltage should be consistent with VDDIO voltage, or there probably is black screen fault when power on.


Mechanical Drawing of 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface


Mechanical Drawing of 9 Inch LCD Display Screen 800*1280 350nits 40PIN MIPI Interface
